Raspberry Pi 3 Model B+ Camera Module 1080p 720p Mini Camera 5MP Webcam Video Camera compatible for Raspberry Pi 2 Model B

Price: US $6.40

Purchase now

SAVE 0%! The Besf Offer Raspberry Pi 3 Model B+ Camera Module 1080p 720p Mini Camera 5MP Webcam Video Camera compatible for Raspberry Pi 2 Model B From Livetime Store

Raspberry Pi 3 Model B+ Camera Module 1080p 720p Mini Camera 5MP Webcam Video Camera compatible for Raspberry Pi 2 Model B

You Get Discount 0% Original Price is US $6.40, If You Buy it Now until 2018-07-27 You Just Pay For US $6.40 Buy It Now

Raspberry Pi 3 Model B+ Camera Module 1080p 720p Mini Camera 5MP Webcam Video Camera compatible for Raspberry Pi 2 Model B

Product Description

The customer who buy this product also pay attention to these products:

Raspberry Pi 3 Camera Kit 5MP Focal Adjustable Night Version Camera+ Acrylic Holder +IR Light +FFC Cable for Raspberry Pi Zero W 2018 Raspberry Pi 3 Model B+ Plus Kit 16 32GB Micro SD Card +Fan + 2.5A Switch Power Adapter+ HDMI Cable for Raspberry Pi 3 B+ 2017 Raspberry Pi Camera 5MP OV5647 DIY Camera Module Larger Size Monitor Camera for Raspberry Pi 3 2 DIY Doorbell Camera Raspberry Pi 3 Model B+ IR-Cut Camera 175 Degree Fish Eye 5MP Day Night Vision Automatic Switch Camera Focus Adjustable Camera C0908-16G-RS Raspberry Pi 3 Starter Kit Acryllic Case + 16 G SD TF Card + CPU Cooling Fan + Copper Aluminum Heat Sink support Raspberry Pi 2
Raspberry Pi 3 Camera 5MP Webcam Camera Module Support Raspberry Pi Zero W V1.3 + 16 cm Raspberry Pi Zero CM FFC 2.4G Wireless Mini Keyboard Spanish Russian German version Mouse Touchpad Remote Control Backlight Keyboard for Android TV Box 7 inch Raspberry Pi 3 B+ Touch Screen 1024*600 800*480 Capacitive Touchscreen LCD HDMI Interface TFT Display + Acrylic Holder Latest Raspberry Pi 3 IR-Cut Camera 5MP Night Vision Day and Night Switch Camera Module for Rasberry Pi 2 Model B Raspberry Pi Camera RPI Fisheye Wide Angle Night Version Camera + Acrylic Holder + IR Light + FFC Cable for Raspberry Pi 3 B+/ 3 New 210 pcs/lot Screws Kits Copper / Nylon Column Screw Nuts Suitable for all kinds of Arduino / Raspberry Pi Project




    Raspberry Pi 3 Model B + Camera Module 1080p 720p Mini Camera 5MP Webcam Video compatible for Raspberry Pi 3 2



Parameter:

Shot:1/4   5M

Aperture:2.9

Focal length:3.29

FOV: 65 degree

Sensor type: OmniVision OV5647 Color CMOS QSXGA (5-megapixel)

Sensor size: 3.67 x 2.74 mm (1/4" format)

Pixel Count: 2592 x 1944

Pixel Size: 1.4 x 1.4 um

Lens: f=3.6 mm, f/2.9

Angle of View: 54 x 41 degrees

Field of View: 2.0 x 1.33 m at 2 m

Full-frame SLR lens equivalent: 35 mm

Fixed Focus: 1 m to infinity

Video: 1080p at 30 fps with codec H.264 (AVC)

Up to 90 fps Video at VGA

Board size: 25 x 24 mm (not including flex cable)

Support Raspberry Pi 3 Model B+



If you want to buy night version camrea,please click here to buy:

Raspberry Pi 3 Camera Module Night Vision OV5647 5MP Adjustable Focal Camera (F)+ 2 Infrared Sensor LED Lights + 15cm FFC



Here is the holder for the camera:

Raspberry Pi 3 Camera Holder Camera Module Bracket Lens Mount Support Raspberry Pi 2 Camera



Package Iist:

1 X 5MP Raspberry Pi  Camera

1 X 15 cm Cable

23457

2

Using steps:

1.Please ensure the raspberry Pi system is the newer version, and open the camera function.Type the command: sudo raspi - config and check the camera function of the fifth.The picture below:

C02843

2. Then select: Enable

C0284005





3. Then the system return to the interface itself. Choose the “Finish “ , it will restart , If it doesn\'t restart itself , please restart it manual  ( by yourself )

finish3

4. After the raspberry pi system restart , you can use raspberry pi camera now.

If you want to take photo, you can run the command : raspistill

For example,input: raspistill –t 2000  -o 1.jpg
-t: ( the time of waiting to take the photo ,5000 is five seconds). – o 1.jpg (1.jpg is command of file)

Tip:

Hardware connection:
1. Soft cable, 90-degree vertical connector, HDMI port next to it. When connecting the contact side facing the HDMI interface.
2. Remove the protective film before using the lens
3. bare boards, pay attention to ESD damage, guard against static electricity!

Software:
1. RPi firmware and raspi-config has been updated to the camera, do a apt-get update; apt-get upgrade;
2. raspi-config, select the camera, start RPi firmware in the camera driver, then reboot
3. Use the command-line program raspivid and raspistill operating camera to capture video clips or images
4. The captured video clip needs to play with mplayer
