1m 2m 3m 4m 5m WS2812B WS2812 Led Strip,Individually Addressable Smart RGB Led Strip,Black/White PCB Waterproof IP30/65/67 DC5V

Price: US $2.15

Purchase now

SAVE 14%! The Besf Offer 1m 2m 3m 4m 5m WS2812B WS2812 Led Strip,Individually Addressable Smart RGB Led Strip,Black/White PCB Waterproof IP30/65/67 DC5V From Xnbada Store

1m 2m 3m 4m 5m WS2812B WS2812 Led Strip,Individually Addressable Smart RGB Led Strip,Black/White PCB Waterproof IP30/65/67 DC5V

You Get Discount 14% Original Price is US $2.50, If You Buy it Now until 2018-09-24 You Just Pay For US $2.15 Buy It Now

1m 2m 3m 4m 5m WS2812B WS2812 Led Strip,Individually Addressable Smart RGB Led Strip,Black/White PCB Waterproof IP30/65/67 DC5V

Product Description

123456789888
Pay attention:
1. Led strip welded by 0.5m is very normal in an electronic product, not a quality problem.if you mind this, do not place order!
2. WS2812B Led strip can be cut buy every "one" led chip!
3. IP30:  Non- Waterproof
    IP65: Waterproof in Silicon Coating
    IP67: Waterproof in SiliconTube
4. WS2812B Led Strip Work With DC5V,And it must need a WS2812B Led Controller Control it
if the order no more than $5 ,no tracking number !!

About how to choose Led Power(End of this link have led power and led controller link choose):
Example:
As one chip is about 0.3w,if you buy is 5m 30led(total led strip is 150leds) ,so 5m 30 led strip is 0.3W*150=45W
And this led strip is 5V,So 45W / 5V=9A,We can calculate this led strip better at least 9A......

Product Decsription:

1) WS2812B Led Strip is Powered By "5V Power Supply" (Not Included) And Is Controlled By A Single Data Line From A Suitable Controller (Not Included).

2) 3-Pin JST Connector Included: Red:VCC, Blue:GND, Green:DATA.

3) The Strip Has 3M Adhesive Tape On The Back(Except Ip67). Installation Surface Must Be Smooth, Clean And Dry.

4) Led Strip Can Be Cut Between Every Led To Create Custom Lengths.

5)Do Not Bend Strip Sharply.

6)Longer Runs Should Be Powered From Both Ends To Reduce Voltage Drop.

7) 3-Pin JST Connector Wire is 20AWG.

Products Application:
WS2812B dream color strips can be used for TV hotel, KTV, bar, game room and other leisure, entertainment decoration to heighten the atmosphere, car chassis, car decoration, shop decoration, home decoration and other decoration.

product details:
Input voltage: DC5V
Power: 30leds/m----9watt/meter
            60leds/m----18watt/meter
            74leds/m----22.2watt/meter
            96leds/m----28.8watt/meter
            144leds/m----43.2watt/meter
LED resource: WS2812B led(5050 SMD RGB LED with built-in improved version of ws2811 ic)
LED: each LED is separately controlled
IC Type: improved version ws2812 IC(built inside the 5050 smd rgb led)
Of IC: 1 IC drives 1 led chip
Pixels: 30/60/74/96/144/meter
Pitch: 16.6mm(1000/64)
Grey scale: 256
Bits/color: 8-bits/color
FPC Width: 30leds/m----10mm
                   60leds/m----10mm
                   74led/m---12mm
                   96led/m---12mm
                   144leds/m----12mm
FPC color: black/white
Protection rate: IP30/ IP65 /IP67
Colors: Full color RGB, dream color changing
Cuttable: every LED is cuttable
Package:in anti-static bag,IP30 IP65 with 3M adhensive tape on the back(IP67 without 3M adhensive)
 2345_image_file_copy_3
package include:
1m/2m/3m/4m/5m ws2812b led strip
